Counters
SM 1-47 D014/D015/D078/D079
Installation
If you are installing the key card …
1. Remove the rear cover.
2. Remove the control box cover.
3. Remove the cutout [A] in the rear cover.
4. Attach the circuit board [A] above the controller board ( x4).
5. Connect the small cable [B] to the circuit board ( x1).
