Cover Interposer Tray CI5000 (B835)
SM 1-129 D014/D015/D078/D079
Installation
You must use the Relay Guide Plate – Short (12-in.)
10. Remove the ground plate [C] from the bottom cross-piece ( x2).
11. Turn the ground plate over.
12. Reattach the ground plate with the same screws as shown ( x2).
13. Remove the interface connector cover [A].
14. Attach the rear docking bracket [B] ( x2).
15. Attach the front docking bracket [C] ( x2).
16. If the Z-Folding Unit will be installed, loosen the screws for the rear runner [A] and front
runner [B].
17. Push the runners in and re-fasten them again with the screws.
