Service Call Tables
D014/D015/D078/D079 4-56 SM
Upper Transport Motor Error (Proof Tray): B830
SC731 B
No encoder pulse signal is
detected for the upper
transport motor within 600 ms.
The 1st failure causes this SC
code.
 Upper transport motor
disconnected, defective
 Finisher connection to upper
transport motor loose, defective
 Upper transport motor blocked by
an obstruction
 Upper transport motor defective
 Finisher main board defective
Shift Tray Exit Motor: 3K Finisher B830
SC732 D
The shift tray exit motor is not
operating.
 Motor harness loose, broken,
defective
 Motor is blocked by an obstruction
 Motor defective
 Finisher main control board
defective
Stapler Exit Motor: B830
SC733 D
The stapler exit motor
is not operating.
 Motor harness loose, broken, defective
 Motor is blocked by an obstruction
 Motor defective
 Finisher main control board defective
