Service Call Tables
SM 4-57 D014/D015/D078/D079
Trouble-
shooting
Upper Tray Junction Gate Motor: 3K Finisher B830
SC734 B
The upper tray junction gate
HP sensor did not detect the
gate at the home position
within 200 ms after two
attempts.
-or-
The HP sensor twice detected
the gate at the home position
for more than 200 ms after it
was supposed to open.
Junction gate did not arrive at the
home position within the specified
time
Junction gate did not leave the
home position within the specified
time
Staple Junction Gate Motor Error: B830
SC735 B
The staple tray junction gate
HP sensor did not detect the
gate at the home position
within 200 ms after two
attempts.
-or-
The HP sensor twice detected
the gate at the home position
for more than 200 ms after it
was supposed to open.
Junction gate did not arrive at the
home position within the specified
time
Junction gate did not leave the
home position within the specified
time
