Service Call Tables
D014/D015/D078/D079 4-58 SM
Pre-Stack Junction Gate Motor Error: 3K Finisher B830
SC736 D
The pre-stack junction gate
HP sensor did not detect the
gate at the home position for
within 200 ms after two
attempts.
-or-
The HP sensor twice detected
the gate at the home position
for more than 200 ms after it
was supposed to open.
Junction gate did not arrive at the
home position within the specified
time
Junction gate did not leave the
home position within the specified
time
Pre-Stack Transport Motor Error: B830
SC737 D
The pre-stack
transport motor is not
operating.
Motor harness loose, broken, defective
Motor is blocked by an obstruction
Motor defective
Finisher main control board defective
Pre-Stack Junction Gate Release Motor Error: B830
SC738 D
The pre-stack junction gate
release HP sensor did not
detect the gate at the home
position within 200 ms after two
attempts.
-or-
The HP sensor twice detected
the gate at the home position
for more than 200 ms after it
was supposed to open.
Junction gate did not arrive at the
home position within the specified
time
Junction gate did not leave the
home position within the specified
time
