Ricoh D014 - Page 515

Service Call Tables
SM 4-65 D014/D015/D078/D079
Trouble-
shooting
Clamp Roller Retraction Motor (D373)
SC766 D
The clamp roller did not
return to the home
position within the
specified time.
 Clamp roller mechanism overloaded due
to an obstruction
 Clamp roller HP sensor connector loose,
broken, defective
 Clamp roller HP sensor defective
 Clamp roller retraction motor connector
loose, broken, defective
 Clamp roller retraction motor defective
 Main control board defective
Stack Junction Gate Motor (D373)
SC767 D
The stack junction gate
did not return to the home
position within the
specified time.
 Stack junction mechanism overloaded
due to an obstruction
 Stack junction gate HP sensor connector
loose, broken, defective
 Stack junction gate HP sensor defective
 Stack junction gate motor connector
loose, broken, defective
 Stack junction gate motor defective
 Main control board defective
