Service Call Tables
D014/D015/D078/D079 4-66 SM
Cover Interposer Lift Motor 1 Error
SC770 D
In the first tray:
 The upper limit sensor did not detect the bottom plate within the
specified time after the lift motor switched on to lift the bottom plate.
 The lower limit sensor did not direct the bottom plate within the
specified time after the lift motor switched on to lower the bottom
plate.
Note: In both cases, 1 error count indicates a jam, 2 error counts cause
this SC code.
 Lift motor, upper limit sensor, lower limit sensor harnesses,
connectors loose, broken, defective
 Lift motor defective
 Upper limit sensor defective
 Lower limit sensor defective
Cover Interposer Lift Motor 2 Error
SC771 D
In the second tray:
 The upper limit sensor did not detect the bottom plate within the
specified time after the lift motor switched on to lift the bottom plate.
 The lower limit sensor did not direct the bottom plate within the
specified time after the lift motor switched on to lower the bottom
plate.
Note: In both cases, 1 error count indicates a jam, 2 error counts cause
this SC code.
 Lift motor, upper limit sensor, lower limit sensor harnesses,
connectors loose, broken, defective
 Lift motor defective
 Upper limit sensor defective
 Lower limit sensor defective
