Group 2000
SM 5-75 D014/D015/D078/D079
Service
Tables
2773 TEdge Cor:Sp1 K
Trailing Edge Correction for Special Paper 1: K. Sets the bias applied at the trailing
edge when the image is transferred from ITB to paper by setting the start timing for
SP2774 at the trailing edge. Applied to the trailing edge for black-and-white mode
on Special Paper 1 only.
7 Side1:PTR
12 Side2:PTR
[0 to 250/1%]
2774 TEdge SWT:Sp1 K
Trailing Edge Switch Timing for Special Paper 1: K.
Sets the switch timing that determines the distance from the leading edge where
the settings of SP2773 are applied during image transfer from ITB to paper.
Applied only when in black-and-white mode on Special Paper 1.
[-100 to 0/ 1 mm]
