Group 2000
SM 5-87 D014/D015/D078/D079
Service
Tables
2901 Disp T/H Sn:PCU
Temperature/Humidity Sensor: PCU. This SP displays the temperature (°C) and
humidity (both relative and absolute) readings of the temperature and humidity
sensor located above the M PCU on the right side of the machine. These
readings are updated every 60 sec.
001 to 004 display the current readings.
005 to 008 display the previous readings.
1 Humid:Recent
2 Rel Humid:Recent
3 Abs Humid:Recent
4 Environ:Recent
5 Humid:JobEnd
6 Rel Humid:JobEnd
7 Abd Humid:JobEnd
8 Environ:JobEnd
[0 to 100/ 1 deg (or %rH)
2902 Env Set:PCU
Use these settings to turn off the temperature/humidity sensor, and raise or lower
the level of detection.
[0 to 6/1
0: Sensor Detect
1: LLL
2: LL
3: ML
4: MM
5: MH
6: HH
