R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1028User Manual 1173.9163.02 ─ 62
CALCulate<Ch>:TRANsform:VNETworks:DIFFerential:EMBedding<LogPt>[:
STATe] <Boolean>
Enables or disables differential match embedding for balanced port <LogPt>.
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number (balanced port)
Parameters:
<Boolean> ON | OFF - embedding active or inactive
*RST: OFF
Manual operation: See "Active" on page 614
CALCulate<Ch>:TRANsform:VNETworks:DIFFerential:EMBedding<LogPt>:
TNDefinition <CircuitModel>
Selects the circuit model for differential match embedding.
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number (balanced port)
Parameters:
<CircuitModel> FIMPort | SHLC
Possible circuit models (character data), see Circuit models for
differential match embedding
Manual operation: See "Network" on page 650
CALCulate<Ch>:TRANsform:VNETworks:FSIMulator[:STATe] <Enable>
De/activates the "Fixture Simulator" switch that allows to disable and (re-)enable the
configured deembedding, embedding, balanced ports, and port impedance settings for
the selected channel.
Suffix:
<Ch>
.
Channel number
Parameters:
<Enable>
Manual operation: See "Fixture Simulator" on page 549
SCPI command reference
