R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1079User Manual 1173.9163.02 ─ 62
Return values:
<Results> Measured voltages, either a single value or a comma-separated
list.
Default unit: V
Usage: Query only
Options: R&S ZN-B15/Z15 Var. 03
Manual operation: See "Voltage, Current" on page 558
CONTrol<Ch>:GPIO<Port>:SHUNt?
Returns the shunt resistance (in Ω) selected by the analyzer firmware for the config-
ured current range (see CONTrol<Ch>:GPIO<Port>:RANGe).
The dependency between current range and shunt resistance is displayed in the tables
below.
Note: The high resistance configuration of pins 9 and 10 requires FPGA version 6.1.0
or higher. For older versions of the R&S ZN-B15/Z15 Var. 03, pins 9 and 10 have the
same current range as pins 1 to 8.
Suffix:
<Ch>
.
Channel number
<Port> GPIO port 1, ..., 10
Example:
:CONTrol1:GPIO1:RANGe 20mA
:CONTrol1:GPIO1:SHUNt?
Returns 10 [Ω]
:CONTrol1:GPIO1:RANGe 2mA
:CONTrol:GPIO1:TEST:CLOCk:SHUNt?
Returns 100 [Ω]
:CONTrol1:GPIO1:RANGe 200uA
:CONTrol:GPIO1:SHUNt?
Returns 1000 [Ω]
:CONTrol1:GPIO9:RANGe 0
:CONTrol:GPIO9:SHUNt?
Returns 100000000 [Ω]
:CONTrol1:GPIO9:RANGe 100mA
:CONTrol:GPIO9:SHUNt?
Returns 1 [Ω]
Usage:
Query only
Options: R&S ZN-B15/Z15 Var. 03
Manual operation: See "Range / Shunt" on page 558
Table 7-11: Pins 1 to 8
Range
2 μA 20 μA 200 μA 2 mA 20 mA
Shunt 100 kΩ 10 kΩ 1 kΩ 100 Ω 10 Ω
