Command reference
R&S
®
ZNB/ZNBT
1102User Manual 1173.9163.02 ─ 62
Parameters:
<Boolean> ON | OFF - colorize trace or keep original trace color.
*RST: n/a (a *RST does not affect the setting). In the fac-
tory configuration, OFF is preset.
Example: See DISPlay:CMAP:LIMit[:STATe]
Manual operation: See "Limit Test > Colorize Trace when Failed" on page 744
DISPlay:CMAP:LIMit:FSYMbol[:STATe] <Boolean>
Displays or hides the limit fail symbols (colored squares) on the trace.
Parameters:
<Boolean> ON | OFF - show or hide symbols.
*RST: n/a (a *RST does not affect the setting). In the fac-
tory configuration, ON is preset.
Example: See DISPlay:CMAP:LIMit[:STATe]
Manual operation: See "Limit Test > Show Limit Fail Symbols" on page 744
DISPlay:CMAP:LIMit[:STATe] <Boolean>
Displays all limit lines either with individually configured colors or with the color of the
associated trace(s). The colors of all display elements are defined via DISPlay:
CMAP<DispEl>:RGB.
.
Parameters:
<Boolean> ON - the limit line colors are defined via
DISPlay:CMAP<DispEl>:RGB where <DispEl> = 9 ... 12.
The limit line colors are independent of the trace colors.
OFF - all limit lines have the color of the associated trace.
*RST: n/a (a *RST does not affect the setting). In the fac-
tory configuration, OFF is preset.
Example:
DISP:CMAP:LIMit OFF
Use the trace colors for all limit lines associated with each trace.
Subsequent limit line color definitions will be ignored until indi-
vidual limit settings are enabled again.
DISPlay:CMAP:LIMit:FCOLorize:STATe ON
Assign a different trace color to failed trace sections.
DISPlay:CMAP:LIMit:FSYMbol:STATe OFF
Remove the limit fail symbols from the trace.
Manual operation: See "Limit Test > Use Trc Color for Limit Lines" on page 745
SCPI command reference
