Example:
HCOP:DEV:LANG BMP
Select Windows bitmap format for printer files.
MMEM:NAME 'C:\Screenshots\PLOT1.BMP'
Define a printer file name and specify an existing directory (with-
out creating the file).
HCOP:DEST 'MMEM'; :HCOP
Select 'Print to file' and create the printer file specified before.
HCOPy[:IMMediate]
Initializes the print according to the current HCOPy... configuration.
Example:
HCOP:DEST '<Printer_name>'
Select the printer for the output of screen data.
HCOP
Start printing.
Usage: Event
Manual operation: See "Print" on page 674
HCOPy:ITEM:ALL
Selects the complete screen contents to be printed, including the logo (HCOPy:ITEM:
LOGO[:STATe]), time (HCOPy:ITEM:TIME[:STATe]), and the marker list (HCOPy:
ITEM:MLISt[:STATe]).
Example:
HCOP:ITEM:ALL
Select the complete information to be printed.
HCOP
Start printing.
Usage: Event
HCOPy:ITEM:LOGO[:STATe] <Boolean>
Qualifies whether or not the printed output contains the logo. The default R&S logo (file
Logo.gif) is stored in the Resources\Images subdirectory of the VNA program
directory and can be replaced by another logo.
Parameters:
<Boolean> ON | OFF - logo is included or excluded.
*RST: n/a (*RST does not affect the printer configuration)
Example:
HCOP:ITEM:ALL
Select the complete information to be printed.
HCOP:ITEM:LOGO ON; :HCOP
Include the logo in the printed output and start printing.
