R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1153User Manual 1173.9163.02 ─ 62
<Trace> Optional string parameter: For multiport Touchstone files
(*.snp, n > 1), the parameter refers to a particular S-parame-
ter trace ('S11', 'S12', ...). For ASCII (*.csv) files, the
parameter references a trace name in the file (case sensitive). If
the parameter is omitted, the first trace in the specified file is
imported.
This parameter is not used for power meter correction list files
(*.pmcl).
*RST: n/a
Example: See SOURce:POWer:CORRection:TCOefficient[:STATe]
on page 1356
Usage: Setting only
Manual operation: See "Import File..." on page 531
MMEMory:LOAD:EYE:BPATtern
<TraceName>, <TraceFile>
Loads a user-defined bit pattern for the related eye diagram from a 7-bit ASCII file.
The pattern is repeated until the configured length is reached (see CALCulate<Chn>:
EYE:INPut:LENGth:BITS on page 863).
Loading a pattern from file implicitly sets the type of bit stream to USER (see
CALCulate<Chn>:EYE:INPut:BPATtern:TYPE).
Setting parameters:
<TraceName> Name of the related eye diagram
<TraceFile> String parameter containing the path and file name of the bit pat-
tern file. If the path is omitted, the current directory is used (see
MMEMory:CDIRectory).
Usage: Setting only
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Load Bit Stream" on page 693
MMEMory:LOAD:EYE:JITTer <TraceName>, <TraceFile>
Loads user-defined jitter from a 7-bit ASCII file into the generator simulation of an eye
diagram.
The file must consist of floating point values (in parsable format), separated by any
whitespace and/or line endings.
Setting parameters:
<TraceName> Name of the related eye diagram
<TraceFile> String parameter containing the path and file name of the jitter
file. If the path is omitted, the current directory is used (see
MMEMory:CDIRectory).
