Command reference
R&S
®
ZNB/ZNBT
1152User Manual 1173.9163.02 ─ 62
<CalGroupFile> Optional string parameter to specify the name of the cal group
file. Cal group files must have the extension *.cal. The direc-
tory must not be specified; the analyzer always uses the default
path C:\Users\Public\Documents\Rohde-Schwarz\Vna
\Calibration\Data. If there is no link between <Ch> and the
specified file, the command has no effect. If no file is specified,
the command resolves any link between <Ch> and an arbitrary
cal group file.
Example: See MMEMory:LOAD:CORRection
Usage: Setting only
Manual operation: See "Resolve Pool Link / Remove Pool Link" on page 536
MMEMory:LOAD:CORRection:TCOefficient<Ch>
<TraceFile>[, <Trace>[,
<DeEmbedding Position>]]
Loads two-port transmission coefficients from the specified power meter correction file
or trace file to channel <Ch>.
Suffix:
<Ch>
.
Channel number
Parameters:
<DeEmbedding
Position>
BOTH | DUT | PM
Determines the two-port the command refers to:
DUT
The two-port between VNA and DUT (during measurement)
PM
The two-port between VNA and PM (during power calibration)
BOTH
Both positions
(parameter omitted)
If the parameter is omitted, the command refers to the two-port
selected using SOURce<Ch>:POWer<PhyPt>:CORRection:
TCOefficient:CALibration.
Setting parameters:
<TraceFile> String parameter specifying the name and directory of the loa-
ded trace file. The R&S ZNB/ZNBT supports power meter cor-
rection list files (*.pmcl, generated using MMEMory:STORe:
CORRection:TCOefficient<Ch>), *csv, and Touchstone
(*.s1p, *.s2p, ...) files.
If no path is specified the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
The file extensions *.s<n>p, *csv, and *.pmcl for Touch-
stone, ASCII, and power meter correction list files are manda-
tory.
*RST: n/a
