Command reference
R&S
®
ZNB/ZNBT
1168User Manual 1173.9163.02 ─ 62
<CalGroupFile> String parameter to specify the name of the created cal group
file. There is no need to specify the directory path and file exten-
sion; the analyzer uses the default cal pool directory
C:\Users\Public\Documents\Rohde-Schwarz\Vna
\Calibration\Data and a *.cal extension.
Example: See MMEMory:LOAD:CORRection
Usage: Setting only
Manual operation: See "Add / Add All... / Replace / Apply / Apply to All"
on page 535
MMEMory:STORe:CORRection:TCOefficient<Ch>
<PmclFile>
Saves two-port transmission coefficients of channel <Ch> to a power meter correction
list file.
Suffix:
<Ch>
.
Channel number
Parameters:
<DeEmbedding
Position>
BOTH | DUT | PM
Determines the two-port the command refers to:
DUT
The two-port between VNA and DUT (during measurement)
PM
The two-port between VNA and PM (during power calibration)
BOTH
Both positions
(parameter omitted)
If the parameter is omitted, the command refers to the two-port
selected using SOURce<Ch>:POWer<PhyPt>:CORRection:
TCOefficient:CALibration.
Setting parameters:
<PmclFile> String parameter specifying the name and directory of the cre-
ated power meter correction list file. The file extension *.pmcl
is mandatory.
If no path is specified, the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
*RST: n/a
Example: See SOURce:POWer:CORRection:TCOefficient[:STATe]
Usage: Setting only
Manual operation: See "Recall... / Save..." on page 531
MMEMory:STORe:EYE:MASK <TraceName>, <TraceFile>
Stores a user-defined eye mask to a 7bit ASCII file.
