Command reference
R&S
®
ZNB/ZNBT
1207User Manual 1173.9163.02 ─ 62
[SENSe<Ch>:]CORRection:COLLect:FIXTure:SAVE....................................................... 1236
[SENSe<Ch>:]CORRection:COLLect:FIXTure:STARt...................................................... 1236
[SENSe<Ch>:]CORRection:COLLect:LOAD:SELected.................................................... 1237
[SENSe<Ch>:]CORRection:COLLect:METHod:DEFine....................................................1238
[SENSe:]CORRection:COLLect:PMETer:ID.....................................................................1240
[SENSe<Ch>:]CORRection:COLLect:SAVE:SELected:DEFault........................................ 1240
[SENSe<Ch>:]CORRection:COLLect:SAVE:SELected[:DUMMy]...................................... 1241
[SENSe<Ch>:]CORRection:COLLect:SCONnection<PhyPt>............................................ 1242
[SENSe<Ch>:]CORRection:COLLect[:ACQuire]:SELected <Type>, <TestPort>[,
<SecondPortOrAdapter>[, <Dispersion>[, <DelayTimePhase>]]]
Starts the acquisition of measurement data for the selected standard and port(s). The
standards are reflection or transmission standards and can be connected to arbitrary
analyzer ports.
Note:
●
The calibration measurement has a variable timeout: Timeout = (Sweep time /
Number of sweep points) * 3 + 0.1 s
The timeout may be reached e.g. while the measurement waits for the specified
trigger event. It is used for all standard measurements including power calibration
sweeps.
●
For a sliding match, the R&S ZNB/ZNBT can acquire measurement data for up to
20 positions per port. Multiple calls of
[SENSe<Ch>:]CORRection:COLLect[:ACQuire]:SELected SLIDe,
<TestPort> for the same test port, implicitly increases the position until position
20 has been recorded. Subsequent calls will start over at position 1, overwriting the
previously acquired data.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Setting parameters:
<Type> THRough | OPEN | SHORt | OSHort | OSHort1 | OSHort2 |
OSHort3 | MATCh | NET | ATT | REFL | SLIDe | ISOLation |
LINE | LINe1 | LINe2 | LINe3 | UTHRough | POWer
Standard types: Through, Open, Short, Match, Symmetric Net-
work (NET), Attenuation (ATT), Reflect, Sliding Match (SLIDe),
Line1 (LINE1 and LINE are synonymous), Line2 and Line3 (esp.
for TRL calibration), Offset Short 1 to 3 (OSHort), Unknown
Through, power meter (for SMARTerCal).
ISOLation is not a physical standard: to measure the isolation
(supported for transmission normalization and TOSM only!) it is
recommended to suitably terminate the related test ports (e.g.
with 50 Ω loads).
<TestPort>
Test port number.
For a transmission standard or an adapter that is used as a
"through", the input and output port numbers must be specified.
For reflection standards, only one port number is required.
*RST: n/a
