SYSTem:DISPlay:COLor <ColorScheme>

Selects the color scheme for all diagram areas in the active recall set.

Parameters:

<ColorScheme> UDEFined | DBACkground | LBACkground | BWLStyles |

BWSolid

DBACkground - dark background

LBACkground - light background

BWLStyles - black and white line styles

BWSolid - black and white solid

Example:

SYST:DISP:COL LBAC

Independent of the selected color scheme, hardcopies are

always generated with the light background scheme.

Manual operation: See "Color Scheme" on page 741

SYSTem:DISPlay:CONDuctances <Boolean>

Changes the presentation of "capacitance C<i> in parallel with resistance R<i>" circuit

blocks in lumped de/embedding networks.

Parameters:

<Boolean> ON - display conductances

OFF - display capacitaces

Manual operation: See "Conductance in Embedding Networks" on page 756

SYSTem:DISPlay:DIALogs:SETup:MCAL[:STATe] <Boolean>

Enables/disables multiple calibrations in the calibration wizard.

Parameters:

Manual operation: See "Multiple Cal in Calibration Wizard" on page 754

SYSTem:DISPlay:TRACes:CCOunt <ColorCount>

Defines the maximum number of trace colors (trace properties for the user defined

color scheme defined using DISPlay:CMAP<DispEl>:RGB.

Parameters:

<ColorCount> Range: 1 to 100

Manual operation: See "Number of Trace Colors" on page 756

SYSTem:DISPlay:UPDate <Activate>

Switches the display on or off while the analyzer is in the remote state. The command

has no effect while the analyzer is in the local operating state.
