R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1435User Manual 1173.9163.02 ─ 62
Example: See TRIGger<Ch>[:SEQuence]:MULTiple:SOURce
Manual operation: See "... /Source/ ..." on page 441
TRIGger<Ch>[:SEQuence]:MULTiple:SOURce <Sequence>[, <TrigSource>]
Selects the source of the trigger events the analyzer uses to start a measurement
sequence in multiple trigger mode (TRIGger<Ch>[:SEQuence]:SOURce MULTi
ple).
Suffix:
<Ch>
.
Channel number
Parameters:
<Sequence> SWEep | SEGMent | POINt | PPOint
Triggered measurement sequence
PPOint denotes "partial measurement"; see TRIGger<Ch>[:
SEQuence]:LINK.
<TrigSource> IMMediate | EXT1 | EXT2 | E1A2 | E1O2 | MANual
Trigger source for the triggered measurement sequence
IMMediate
Free run measurement (untriggered)
EXT1
Trigger event at Trigger In or Pin 2 of User Port
EXT2
Trigger event at pin 25 of User Port.
E1A2
Trigger events at EXT1 AND EXT2
E1O2
Trigger event at EXT1 OR EXT2
MANual
Trigger event generated by pressing the "Manual Trigger" soft-
key
Example:
TRIG:MULT:SOUR SWE, EXT1; SOUR POIN, EXT2
Select external trigger 1 as a trigger source for the entire sweep,
external trigger 2 as a trigger source for each point.
TRIG:MULT:SLOP1 SWE, POS; SLOP2 POIN, POS
Trigger on the rising edges of the external trigger signals 1 and
2.
TRIG:MULT:HOLD POIN, 1ms
Define a trigger delay of 1 ms before each sweep point.
Manual operation: See "... /Source/ ..." on page 441
TRIGger<Ch>[:SEQuence]:SLOPe <Slope>
Qualifies whether the trigger event occurs on the rising or on the falling edge or on the
beginning of the high / low level periods of the external TTL trigger signal.
