R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1438User Manual 1173.9163.02 ─ 62
Parameters:
<EnableTriggOut> Turn trigger output on (ON) or off (OFF, no signal).
*RST: OFF
Example:
TRIGger:CHANnel:AUXiliary:ENABle ON
Turn on the trigger output for channel no. 1 (channel suffix omit-
ted).
TRIGger:CHANnel:AUXiliary:DURation 10 us
Change the width of the output trigger pulses.
TRIGger:CHANnel:AUXiliary:POSition BEFore
Send the output trigger pulses before data acquisition starts.
TRIGger:CHANnel:AUXiliary:INTerval SWEep
Send one output trigger pulse per sweep.
TRIGger:CHANnel:AUXiliary:OPOLarity POSitive
Select positive polarity for the output trigger pulses.
TRIGger:CHANnel<Ch>:AUXiliary:INTerval <Type>
Specifies whether the trigger output pulses are sent once every partial measurement
(POINt) or once every sweep.
Suffix:
<Ch>
.
Channel number
Parameters:
<Type> POINt | SWEep
*RST: SWEep
Example: See TRIGger:CHANnel<Ch>:AUXiliary[:ENABle]
TRIGger:CHANnel<Ch>:AUXiliary:OPOLarity <Type>
Selects the polarity of the output trigger pulses; see Figure 7-1.
Suffix:
<Ch>
.
Channel number
Parameters:
<Type> POSitive | NEGative
*RST: NEGative
Example: See TRIGger:CHANnel<Ch>:AUXiliary[:ENABle]
TRIGger:CHANnel<Ch>:AUXiliary:POSition <Type>
Specifies whether the trigger output pulse is sent before or after the selected sweep
interval (see TRIGger:CHANnel<Ch>:AUXiliary:INTerval).
SCPI command reference
