CALCulate<Chn>:LIMit:RDOMain:FORMat <UnitRef>
Deletes the existing limit line and (re-)defines the physical units of the response values
of the limit line. The units of the stimulus values are defined via CALCulate<Chn>:
LIMit:CONTrol:DOMain.
Tip: This command is complemented by CALCulate<Chn>:LIMit:RDOMain:
COMPlex and CALCulate<Chn>:LIMit:RDOMain:SPACing.
Suffix:
<Chn>
.
Channel number used to identify the active trace.
Setting parameters:
<UnitRef> COMPlex | MAGNitude | PHASe | REAL | IMAGinary | SWR |
GDELay | L | C
Keyword for the physical unit of the response values. The
parameters form four groups: COMPlex, REAL, IMAGinary, and
SWR select dimensionless numbers (U) for the limit line. MAG-
Nitude selects relative units (dB). PHASe selects phase units
(deg). GDELay selects time units (s). L selects inductance units
(H/Henry). C selects capacitance units (F/Farad).
Usage: Setting only
CALCulate<Chn>:LIMit:RDOMain:SPACing <Format>
Deletes the existing limit line and (re-)defines the physical units of the response values
of the limit line. The units of the stimulus values are defined via CALCulate<Chn>:
LIMit:CONTrol:DOMain.
Tip: This command is complemented by CALCulate<Chn>:LIMit:RDOMain:
COMPlex and CALCulate<Chn>:LIMit:RDOMain:FORMat.
Suffix:
<Chn>
.
Channel number used to identify the active trace.
Setting parameters:
<Format> LINear | LOGarithmic | DB | SIC
Keyword for the physical unit of the response values.
Default unit: dB (irrespective of the parameter selected)
Usage: Setting only
CALCulate<Chn>:LIMit:LOWer:STATe <Boolean>
CALCulate<Chn>:LIMit:UPPer:STATe <Boolean>
These commands switch the lower and upper limit check on or off. Lower limit line seg-
ments are assigned even numbers; upper limit line segments are assigned odd num-
bers; see CALCulate<Chn>:LIMit:LOWer[:DATA] and CALCulate<Chn>:
LIMit:UPPer[:DATA]. CALCulate<Chn>:LIMit:LOWer:STATe does not affect
segments with odd numbers; CALCulate<Chn>:LIMit:UPPer:STATe does not
affect segments with even numbers.
