R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1477User Manual 1173.9163.02 ─ 62
Suffix:
<Ch>
.
Channel number of the calibrated channel.
Setting parameters:
<Standard> THRough | OPEN1 | OPEN2 | OPEN12 | SHORt1 | SHORt2 |
SHORt12 | MATCh1 | MATCh2 | MATCh12 | NET | ATT |
IMATch12 | REFL1 | REFL2 | SLIDe1 | SLIDe2 | SLIDe12 |
LINe1 | LINe2 | LINe3 | M1O2 | O1M2 | OSHort1 | OSHort11 |
OSHort12 | OSHort13 | OSHort2 | OSHort21 | OSHort22 |
OSHort23 | M1S2 | S1M2 | UTHRough
Standard types: Through (between port 1 and 2), Open, Short,
Match (MATCh12 and IMATch12 are synonymous), Symmetric
Network (NET), Attenuation (ATT), Reflect, Sliding Match
(SLIDe), Line1 (LINe1 and LINE are synonymous), Line2 and
Line3 (esp. for TRL calibration), Match/Open (M1O2, O1M2),
Match/Short (M1S2, S1M2), Offset Short (OSHort), Unknown
Through (UTHRough).
The numbers in the parameter names denote the analyzer ports.
Two numbers 12 mean that two separate calibrations are per-
formed at ports 1 and 2. For Offset Short standards, the first
number denotes the port (1 or 2), the second number denotes
the number of the standard (1 to 3).
*RST:
ON
<Dispersion> Optional status parameter for UTHRough standard:
OFF - unknown through standard is non-dispersive.
ON - unknown through standard is dispersive.
*RST: OFF
<Delay> Optional entry of delay time or phase for UTHRough standard:
<numeric> - entry of the delay time in ps (for non-dispersive
standards) or of an estimate of the phase at the start frequency
of the sweep in deg (for dispersive standards). See also back-
ground information for [SENSe<Ch>:]CORRection:
COLLect[:ACQuire]:SELected.
AUTO - the analyzer determines the delay time or phase during
the calibration sweep.
*RST: AUTO
Example: See [SENSe<Ch>:]CORRection:COLLect:SAVE[:DUMMy]
Usage: Setting only
[SENSe<Ch>:]CORRection:COLLect:METHod <CalType>
Selects a one-port or two-port calibration type for channel <Ch> at ports 1/2.
Tip: Use the generalized command [SENSe<Ch>:]CORRection:COLLect:
METHod:DEFine to select the calibration type for arbitrary analyzer ports or a multiport
calibration type.
R&S ZVR/ZVABT compatible commands
