R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
909User Manual 1173.9163.02 ─ 62
RESonant
The 2x thru test coupon will be split and used directly for deem-
bedding (parameter value 3).
This option may be more accurate when the fixture and 2x Thru
have the same impedance at every location
Manual operation: See "Test Coupons > Insertion Loss" on page 636
CALCulate:FMODel:ISD:COUPon:MEASure
For a fixture modeling with the ISD tool and coupon types SYMMetric2x | OPEN1x |
SHORt1x (see CALCulate:FMODel:ISD:COUPon:TYPE), this command starts the
measurement of the coupon at the active ports (see CALCulate:FMODel:
ISD<Ph_pt>:COUPon[:STATe]).
Example:
See Chapter 8.2.8, "Fixture modeling", on page 1527
Usage: Event
Manual operation: See "Measure / Measure Open / Measure Short" on page 630
CALCulate:FMODel:ISD:COUPon:MEASure:FILename <String>
For a fixture modeling with the ISD tool and coupon types SYMMetric2x | OPEN1x |
SHORt1x (see CALCulate:FMODel:ISD:COUPon:TYPE), this command loads the
coupon properties from a Touchstone file.
Parameters:
<String> Path to the Touchstone file, either absolute or relative to the
selected working directory (CALCulate:FMODel:DIRectory).
Manual operation: See "Load File / 1x Open Preset / 1x Short Preset" on page 630
CALCulate:FMODel:ISD:COUPon:MEASure:FILename:CLEar
Invalidates the file path previously set using CALCulate:FMODel:ISD:DUT:
MEASure:FILename, CALCulate:FMODel:ISD:COUPon:MEASure:OPEN:
FILename, or CALCulate:FMODel:ISD:COUPon:MEASure:SHORt:FILename.
Usage:
Event
Manual operation: See "Load File / 1x Open Preset / 1x Short Preset" on page 630
CALCulate:FMODel:ISD:COUPon:MEASure:OPEN
For a fixture modeling with the ISD tool and coupon type OPSHort1x (see
CALCulate:FMODel:ISD:COUPon:TYPE), this command starts the measurement of
the Open coupon at the active ports (see CALCulate:FMODel:ISD<Ph_pt>:
COUPon[:STATe]).
Usage:
Event
SCPI command reference
