Command reference
R&S
®
ZNB/ZNBT
910User Manual 1173.9163.02 ─ 62
Manual operation: See "Measure / Measure Open / Measure Short" on page 630
CALCulate:FMODel:ISD:COUPon:MEASure:OPEN:FILename <String>
For a fixture modeling with the ISD tool and coupon type OPSHort1x (see
CALCulate:FMODel:ISD:COUPon:TYPE), this command loads the properties of the
Open coupon from a Touchstone file.
Parameters:
<String> Path to the Touchstone file, either absolute or relative to the
selected working directory (CALCulate:FMODel:DIRectory).
Manual operation: See "Load File / 1x Open Preset / 1x Short Preset" on page 630
CALCulate:FMODel:ISD:COUPon:MEASure:SHORt
For a fixture modeling with the ISD tool and coupon type OPSHort1x (see
CALCulate:FMODel:ISD:COUPon:TYPE), this command starts the measurement of
the Short coupon at the active ports (see CALCulate:FMODel:ISD<Ph_pt>:
COUPon[:STATe]).
Usage:
Event
Manual operation: See "Measure / Measure Open / Measure Short" on page 630
CALCulate:FMODel:ISD:COUPon:MEASure:SHORt:FILename <String>
For a fixture modeling with the ISD tool and coupon type OPSHort1x (see
CALCulate:FMODel:ISD:COUPon:TYPE), this command loads the properties of the
Short coupon from a Touchstone file.
Parameters:
<String> Path to the Touchstone file, either absolute or relative to the
selected working directory (CALCulate:FMODel:DIRectory).
Manual operation: See "Load File / 1x Open Preset / 1x Short Preset" on page 630
CALCulate:FMODel:ISD<Ph_pt>:COUPon[:STATe] <Boolean>
For a fixture modeling with the ISD tool, this command allows to specify the ports to
which the test coupon is connected.
This has to be defined before measuring the test coupon (using CALCulate:FMODel:
ISD:COUPon:MEASure or CALCulate:FMODel:ISD:COUPon:MEASure:OPEN and
CALCulate:FMODel:ISD:COUPon:MEASure:SHORt).
Suffix:
<Ph_pt>
.
Physical port number
Parameters:
<Boolean>
1 (ON, true) if the test coupon is connected to port <Ph_pt>, 0
(OFF, false) otherwise
