Command reference
R&S
®
ZNB/ZNBT
947User Manual 1173.9163.02 ─ 62
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> Marker number (ignored for reference markers)
Parameters:
<Active> Boolean
Manual operation: See "Excursion Settings" on page 401
CALCulate<Chn>:MARKer<Mk>:FORMat <OutFormat>
CALCulate<Chn>:MARKer<Mk>:REFerence:FORMat <OutFormat>
Sets/queries the output format for the (complex) value of the related marker.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> Marker number (ignored for reference markers)
Parameters:
<OutFormat> MLINear | MLOGarithmic | PHASe | POLar | GDELay | REAL |
IMAGinary | SWR | LINPhase | LOGPhase | IMPedance |
ADMittance | DEFault | COMPlex | MDB | MLPHase |
MDPHase | MIMPedance | PIMPedance | PADMittance |
MADMittance | MPIMpedance | MPADmittance | INDX
DEFault means the reference marker is formatted according
the related trace's default marker format (see
CALCulate<Chn>:MARKer:DEFault:FORMat).
For the other marker formats, see CALCulate<Chn>:MARKer:
DEFault:FORMat and the description in "Marker format"
on page 107.
*RST:
DEFault
Manual operation: See "Marker Format" on page 394
CALCulate:MARKer:FUNCtion:BWIDth:GMCenter <arg0>
Defines how bandfilter searches calculate the center frequency of the passband or
stopband.
Parameters:
<arg0> ON – use geometric mean of lower and upper band edge
OFF – use arithmetic mean
*RST: n/a (*RST does not affect the calculation rule; the
factory setting is ON/geometric mean)
Manual operation: See "Geometric Calculation of Bandfilter Center" on page 759
