Command reference
R&S
®
ZNB/ZNBT
1081User Manual 1173.9163.02 ─ 62
Parameters:
<Voltage> Range: -7 to +15 V
Increment: 5 mV
Default unit: V
Manual operation: See "Voltage / Output Voltage" on page 557
CONTrol<Ch>:GPIO:VOLTage:OUTPut
Applies the current output voltage and current range (shunt) settings to the RFFE/
GPIO pins.
Same function as CONTrol<Ch>:RFFE:TEST:OUTPut on page 1092.
Suffix:
<Ch>
.
Channel number
Usage: Event
Manual operation: See "Apply" on page 557
CONTrol:HANDler:A[:DATA] <DecValue>
CONTrol:HANDler:B[:DATA] <DecValue>
CONTrol:HANDler:C[:DATA] <DecValue>
CONTrol:HANDler:D[:DATA] <DecValue>
CONTrol:HANDler:E[:DATA] <DecValue>
CONTrol:HANDler:F[:DATA] <DecValue>
CONTrol:HANDler:G[:DATA] <DecValue>
CONTrol:HANDler:H[:DATA] <DecValue>
The setting commands write data to ports A, B, C, D, E, F, G, H. To write data to a port,
the port must be configured as an output port (see example). By default, the port lines
have negative logic: A "0" at a pin corresponds to a high signal, a "1" to a low signal.
The logic can be changed using CONTrol:HANDler:LOGic POSitive. When writing
to port G, port C must be configured as an output port. When writing to port H, port C
and port D must be configured as output ports (see CONTrol:HANDler:D:MODE).
The queries read data from ports A, B, C, D, E, F, G, H. If the port is an output port, the
queries return the last value that was written to the port.
Parameters:
<DecValue> Decimal representation fo an n-bit binary value. The ranges are:
Port A: 0 to 255 (pins A7 ... A0)
Port B: 0 to 255 (pins B7 ... B0)
Port C: 0 to 15 (pins C3 ... C0)
Port D: 0 to 15 (pins D3 ... D0)
Port E: 0 to 255 (pins D3 ... D0 C3 ... C0)
Port F: 0 to 65535 (pins B7 ... B0 A7 ... A0)
Port G: 0 to 1048575 (pins C3 ... C0 B7 ... B0 A7 ... A0)
Port H: 0 to 16777215 (pins D3 ... D0 C3 ... C0 B7 ... B0 A7 ...
A0)
The parameters MIN, MAX, DEF are not supported.
