Command reference
R&S
®
ZNB/ZNBT
1096User Manual 1173.9163.02 ─ 62
Suffix:
<Ch>
.
Channel number
Usage: Query only
Manual operation: See "Range" on page 559
CONTrol<Ch>:SEQuence<Nr>:DELay <Delay>
For unsegmented sweeps this command allows to introduce delays between subse-
quent sequence steps and between the final sequence step and the sweep (segment)
start.
The command/switch sequences are defined using CONTrol<Ch>:SEQuence<Nr>:
RFFE<Bus>:COMMand:DATA and CONTrol<Ch>:SEQuence<Nr>:GPIO<Port>:
VOLTage.
Suffix:
<Ch>
.
Channel number
<Nr> Sequence number, defining the order in which the commands
shall be executed.
For every channel and RFFE interface, the sequence numbers
must be consecutive, starting at 1; reusing a sequence number
overwrites a previously defined command.
Parameters:
<Delay> Delay time
Default unit: s
Manual operation: See "Wait (Sweep Sequencer Table)" on page 560
CONTrol<Ch>:SEQuence<Nr>:GPIO<Port>:VOLTage <Voltage>
For unsegmented sweeps this command allows to define the GPIO voltage settings to
be applied at the start of each sweep.
The GPIO ports can be enabled/disabled using CONTrol<Ch>:GPIO<Port>[:
STATe]. Complementary RFFE commands can be defined using CONTrol<Ch>:
SEQuence<Nr>:RFFE<Bus>:COMMand:DATA.
Suffix:
<Ch>
.
Channel number
<Nr> Sequence number, defining the order in which the switches/
commands shall be executed.
For every channel and GPIO port, the sequence numbers must
be consecutive, starting at 1; reusing a sequence number over-
writes a previous voltage setting.
Delays between subsequent settings/command and - finally - the
start of the respective sweep segment can be introduced using
CONTrol<Ch>:SEQuence<Nr>:DELay.
<Port> GPIO port number
