[SENSe<Ch>:]SEGMent<Seg>:SWEep:POINts <SegPoint>
Defines the total number of measurement points in sweep segment no. <Seg>.
Suffix:
<Ch>
.
Channel number
<Seg> Sweep segment number
Parameters:
<SegPoint> Number of points in the segment
Range: 1 to 100001. 1 is allowed if start and stop frequen-
cies are equal.
*RST: 51
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using
default settings.
SEGM:SWE:POIN 401
Increase the number of points to 401.
Manual operation: See "Table Columns" on page 432
[SENSe<Ch>:]SEGMent<Seg>:SWEep:TIME <SegSweepTime>
Sets the duration of the sweep in sweep segment no. <Seg> ("Segment Time"). At the
same time, the command activates separate sweep time setting in all sweep segments
([SENSe<Ch>:]SEGMent<Seg>:SWEep:TIME:CONTrol ON).
Suffix:
<Ch>
.
Channel number
<Seg> Sweep segment number
Parameters:
<SegSweepTime> Segment time. The minimum segment time depends on the
other channel settings, in particular on the number of points
([SENSe<Ch>:]SEGMent<Seg>:SWEep:POINts), the IF
bandwidth ([SENSe<Ch>:]SEGMent<Seg>:BWIDth[:
RESolution]) and the delay for each partial measurement
([SENSe<Ch>:]SEGMent<Seg>:SWEep:DWELl). The maxi-
mum is 1000 s. Changing the duration leaves the number of
points unchanged but directly affects the delay.
Range: Minimum value to 1000 s
*RST: Minimum value, depending on the channel settings.
This default value corresponds to automatic sweep
time setting in manual control.
Default unit: s
