R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1366User Manual 1173.9163.02 ─ 62
Example:
*RST; :SOURce:POWer:CORRection:IMODulation:PORT
'PORT 4'
Select the analyzer port no. 4 as a source port for the receiver
power calibration.
Manual operation: See "Src. for Rcvr. Cal" on page 589
SOURce<Ch>:POWer<PhyPt>:CORRection:IMODulation:UTONe[:ACQuire]
[<CalOnlyPortFreq>]
Starts the source calibration for the upper tone (2
nd
power calibration step for intermo-
dulation measurements), stores and applies the calibration data. The external power
meter used is selected via SOURce<Ch>:POWer<PhyPt>:CORRection:PMETer:ID.
Suffix:
<Ch>
.
Calibrated channel number
Setting parameters:
<CalOnlyPortFreq>
OFF | 0
The reference receiver at port <CalPort> is calibrated for all fre-
quencies that are relevant for any of the ports.
ON | 1
Only those frequencies are calibrated that are relevant for this
port. This results in shorter calibration times.
*RST: 0
Example: See SOURce<Ch>:POWer<PhyPt>:CORRection:
IMODulation:LTONe[:ACQuire]
Usage: Setting only
Manual operation: See "Start Cal Sweep" on page 592
SOURce:POWer:CORRection:NREadings <NoCalSweeps>
Sets a limit for the number of calibration sweeps in the source power calibration. The
command is valid for all channels, ports and external generators.
Equivalent command: SOURce:POWer:CORRection:COLLect:AVERage[:COUNt].
Parameters:
<NoCalSweeps> Number of readings
Range: 1 to 100
*RST: 2
Example: See SOURce<Ch>:POWer:CORRection[:ACQuire]
Manual operation: See "Flatness Cal – Max Iterations" on page 525
SOURce<Ch>:POWer:CORRection:OSOurces[:STATe] <Boolean>
Switches off all other sources during the calibration sweep for channel <Ch>.
SCPI command reference
