Command reference
R&S
®
ZNB/ZNBT
1403User Manual 1173.9163.02 ─ 62
SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:TVNA <TestPort1>[,
<VNAPort1>]...
Sets/gets the test port connections of the VNA in a switch matrix RF connection setup,
i.e. the direct assignments of test ports to physical VNA ports.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Setting parameters:
<TestPort1> Number of the test port.
Test ports must be numbered subsequently starting at 1.
<VNAPort1> Number of the VNA port
Example:
SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
TVNA 6,2,7,4
Test Ports 6 and 7 are assigned to VNA ports 2 and 4.
Manual operation: See "Edit Test Port Connection" on page 799
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:CONFigure:MLVNa {<Matrix VNA
Port Label>, <VNA Port Number>}
Sets/gets the RF connections between switch matrix and VNA. Similar to SYSTem:
COMMunicate:RDEVice:SMATrix<Matr>:CONFigure:MVNA, but uses the front
panel labels of the matrix VNA ports instead.
By default, these labels are only available for some matrix types.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1405)
Setting parameters:
<Matrix VNA Port
Label>
These labels are specified in the corresponding matrix driver file
(see SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:
DEFine on page 1405).
<VNA Port Number>
Range: 1 ... # of RF ports of the VNA
Example: A switch matrix ZV-Z84-02 is used.
SYSTem:COMMunicate:RDEVice:SMATrix1:CONFigure:
MLVNA '1A',1,'2B',2
VNA ports 1 and 2 are connected to matrix VNA ports '1A' and
'2B', respectively
SCPI command reference
