R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1404User Manual 1173.9163.02 ─ 62
Manual operation: See "Edit Matrix VNA Port Connections" on page 798
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:CONFigure:MLTest {<Matrix Test
Port Label>, <TPNumber>}
Sets/gets the matrix test port connections. Similar to SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:CONFigure:MTESt, but uses the front panel labels of
the matrix test ports instead.
By default, these labels are only available for some matrix types.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1405)
Setting parameters:
<Matrix Test Port
Label>
If available, these labels are specified in the corresponding
matrix driver file (see SYSTem:COMMunicate:RDEVice:
SMATrix<Matr>:DEFine on page 1405).
<Test Port Number> Test ports must be numbered subsequently, starting at 1.
Example: A switch matrix ZV-Z82-16 is used.
SYSTem:COMMunicate:RDEVice:SMATrix1:CONFigure:
MLTESt 'A1',1,'B1',2
The first test ports of submatrices A and B are assigned to test
ports 1 and 2, respectively.
Manual operation: See "Edit Test Port Connection" on page 799
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:CONFigure:MTESt
{<MatrixTestPort>, <TestPort>}
Sets/gets the matrix test port connections as a comma-separated list of port numbers
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1405)
Setting parameters:
{<MatrixTestPort> Number of the switch matrix test port
<TestPort>} Number of the test port.
Test ports must be numbered subsequently starting at 1.
SCPI command reference
