R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1405User Manual 1173.9163.02 ─ 62
Example: See SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt
Manual operation: See "Edit Test Port Connection" on page 799
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:CONFigure:MVNA
{<MatrixVNAPort>, <VNAPort>}
Sets/gets the RF connections between switch matrix and VNA as a comma-separated
list of port numbers.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
Suffix:
<Matr>
.
Configuration index of the switch matrix (see SYSTem:
COMMunicate:RDEVice:SMATrix<Matr>:DEFine
on page 1405)
Setting parameters:
{<MatrixVNAPort> Number of the switch matrix VNA port
Range: 1 ... # of VNA ports of the switch matrix
<VNAPort>} Number of the VNA port
Range: 1 ... # of RF ports of the VNA
Example: See SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt
Manual operation: See "Edit Matrix VNA Port Connections" on page 798
SYSTem:COMMunicate:RDEVice:SMATrix:COUNt?
Gets the number of configured switch matrices (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1405)
Usage:
Query only
Manual operation: See "Configured Devices" on page 793
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:DEFine <Unused>, <Driver>,
<Interface>, <Address>
This command allows
●
to configure (i.e. register) a new switching matrix
●
to modify the (management) connection settings of an already configured switching
matrix
●
to get the (management) connection settings of a configured switching matrix
SCPI command reference
