R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1469User Manual 1173.9163.02 ─ 62
<Mk> This numeric suffix is ignored and may be set to any value
because the bandfilter search functions always use markers M1
to M4.
Parameters:
<Bandwidth> Range: -100 dB to 100 dB
Increment: 0.03 dB
*RST: 3 dB
Default unit: dB
Example: See CALCulate<Chn>:MARKer<Mk>:BWIDth
CALCulate<Chn>:MARKer<Mk>:FUNCtion:DELTa:STATe
<Boolean>
Switches the delta mode for marker <Mk> on trace no. <Chn> on or off.
Note: This command is the ZVR-compatible equivalent of CALCulate<Chn>:
MARKer<Mk>:DELTa[:STATe].
Suffix:
<Chn>
.
Channel number used to identify the active trace.
<Mk> Marker number.
Parameters:
<Boolean> ON | OFF - enable or disable the delta mode.
*RST: OFF
CALCulate<Chn>:MARKer<Mk>:FUNCtion[:SELect] <Mode>
CALCulate<Chn>:MARKer<Mk>:REFerence:FUNCtion[:SELect] <Mode>
Selects a search mode for the related marker.
The search can then be initiated using one of the commands:
●
CALCulate<Ch>:MARKer<Mk>:SEARch...
●
CALCulate<Ch>:MARKer:REFerence:SEARch...
●
CALCulate<Ch>:MARKer<Mk>:MAXimum or
CALCulate<Ch>:MARKer<Mk>:MINimum
●
CALCulate<Ch>:MARKer:REFerence:MAXimum or
CALCulate<Ch>:MARKer:REFerence:MINimum
The marker must be created before using CALCulate<Chn>:MARKer<Mk>[:STATe]
ON or CALCulate<Chn>:MARKer<Mk>:REFerence[:STATe] ON.
Note: This command is not needed except for compatibility with ZVR programs. Use
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute or CALCulate<Chn>:
MARKer<Mk>:REFerence:FUNCtion:EXECute to select a search mode and at the
same time initiate the search.
Suffix:
<Chn>
.
Channel number used to identify the active trace.
R&S ZVR/ZVABT compatible commands
