R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
876User Manual 1173.9163.02 ─ 62
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Polygon Setup" on page 705
CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:VERTical <Main>[, <Minor>]
Defines the main [and minor] height of the center polygon in the mask of the related
eye diagram. The geometric interpretation depends on the selected polygon type (see
CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:TYPE on page 875):
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Use CALCulate<Chn>:EYE:MASK:SHAPe:POLYgon:STATe to activate or deacti-
vate the center polygon in the eye mask. The eye mask test is enabled/disabled using
CALCulate<Chn>:EYE:MASK:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Main> Default unit: V
<Minor> Default unit: V
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Polygon Setup" on page 705
CALCulate<Chn>:EYE:MASK:SHOW <Boolean>
Defines the visibility of the configured eye mask in the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Show Mask" on page 703
CALCulate<Chn>:EYE:MASK:STATe <Boolean>
Defines whether the eye mask test shall be run after every recalculation of the related
eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
SCPI command reference
