Depending on the number of available test/DUT ports and the selected fixture tool
(CALCulate:FMODel:DEASsistant:TOOL), choose the appropriate <DutType>.
Parameters:
<DutType> SEX | SEXSe | BX | BXB | BXSE | SE21 | SE22 | NXSE |
NXMSe | NXB | NXMB
SEX
1 x single-ended
SEXSe
1 x 1 single-ended
BX
1 x balanced
BXB
1 x 1 balanced
BXSE
1 x balanced, 1 x single-ended (ISD only)
SE21
2 x 1 single-ended (ISD only)
SE22
2 x 2 single-ended (ISD only)
NXSE
n x single-ended (ISD only)
NXMSe
n x m single-ended (ISD only)
NXB
n x balanced (ISD only)
NXMB
n x m balanced (ISD only; currently not supported )
Options:
R&S ZNB/ZNBT-K220 | R&S ZNB/ZNBT-K230 | R&S ZNB/
ZNBT-K210
Manual operation: See "DUT" on page 655
CALCulate:FMODel:DEASsistant<Ph_pt>:FIXTure:LEFT:TYPE <FixtureType>
CALCulate:FMODel:DEASsistant:FIXTure:RIGHt:TYPE <FixtureType>
Allows you to specify models for the left side (lead-in) and right side (lead-out) of the
DUT, depending on the selected DUT type (CALCulate:FMODel:DEASsistant:
DUT:TYPE on page 890).
Parameters:
<FixtureType> NONE | SE | BALanced | COUPled | UNCoupled
NONE
Only for non-existing right sides (lead-outs).
SE
Single-ended; for single-ended lead-ins/outs
