R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
899User Manual 1173.9163.02 ─ 62
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Length" on page 666
CALCulate:FMODel:DELT:M1L:MEASure
CALCulate:FMODel:DELT:M2L:MEASure
CALCulate:FMODel:DELT:M3L:MEASure
Measures the full set of S-parameters at the active ports (see CALCulate:FMO
Del:DELT<Ph_pt>:M1L|M2L|M3L[:STATe]).
Usage: Event
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Measure" on page 665
CALCulate:FMODel:DELT<Ph_pt>:M1L[:STATe]
<Boolean>
CALCulate:FMODel:DELT<Ph_pt>:M2L[:STATe] <Boolean>
CALCulate:FMODel:DELT<Ph_pt>:M3L[:STATe] <Boolean>
Defines the active ports for the 1st/2nd/3rd line Delta-L measurement (CALCu
late:FMODel:DELT<Ph_pt>:M1L|M2L|M3L:MEASure).
For each measurement, either two or four ports must be active. If the 1-length method
is used (CALCulate:FMODel:DELT:METHod M1L), then four ports must be active for
the first line.
Suffix:
<Ph_pt>
.
Physical port number
Parameters:
<Boolean> ON (1)
Port <Ph_pt> is active in the respective measurement
OFF (0)
Port <Ph_pt> is inactive in the respective measurement
Options: R&S ZNB/ZNBT-K231
Manual operation: See "Ports table" on page 665
CALCulate:FMODel:DELT:MEASurement <Measurement>
Defines whether single-ended or balanced ports are measured for Delta-L characteri-
zations.
Parameters:
<Measurement> SINGleended | BALanced
SINGleended
Single-ended ports only
BALanced
Balanced ports only
SCPI command reference
