Command reference

R&S

ZNB/ZNBT

913User Manual 1173.9163.02 ─ 62

CALCulate:FMODel:ISD:FTIMe:OVERride <Boolean>

If set to true, the flight time for DUT + lead-in is specified using CALCulate:FMODel:

ISD:FTIMe:DUT. Otherwise, it is calculated automatically.

True is equivalent to setting the leadin_dut_time batch mode parameter of the ISD

tool to auto.

Parameters:

Manual operation: See "Auto. flight time for DUT + lead-Ins" on page 636

CALCulate:FMODel:ISD:IMPedance

Enables/disables the impedance correction of the ISD tool.

This is a global setting.

Parameters:

<Boolean> ON (1)

Impedance correction enabled

OFF (0)

Impedance correction disabled

Manual operation: See "Use Impedance Correction" on page 629

CALCulate:FMODel:ISD:OPERation <Operation>

Defines the execution mode of the ISD tool.

Parameters:

<Operation> FAST | ACCurate

ACCurate: normal execution mode

FAST: reduces the execution time to ~50%

In many cases the FAST mode can be enabled with only little

loss of accuracy.

Manual operation: See "Operation (fast/acc)" on page 638

CALCulate:FMODel:ISD:PASSivity <Boolean>

Defines whether the ISD tool shall enforce passivity and reciprocity for the test cou-

pons and the test fixture.

Corresponds to the passive batch mode parameter of the ISD tool.

Parameters:

<Boolean> ON (0): enforce passivity and reciprocity

OFF (0): do not enforce passivity and reciprocity

Manual operation: See "Enforce Passitivity" on page 637
