R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
914User Manual 1173.9163.02 ─ 62
CALCulate:FMODel:ISD:PORT:ORDer <PortOrder>
Defines how the ISD tool shall interpret the DUT + Fixture data (see CALCulate:
FMODel:ISD:DUT:MEASure):
●
NON: ports 1 to N are on the left and ports N+1 to 2*N are on the right
●
ODD: ports 1, 3, 5, etc. are on the left and ports 2, 4, 6, etc. are on the right.
●
ALL: use this to tell the ISD tool that all ports are on the left (i.e. assumed to be
coupled)
Corresponds to the port_order batch mode parameter of the ISD tool.
Parameters:
<PortOrder> ODD | NON | ALL
Manual operation: See "Port Sequence" on page 636
CALCulate:FMODel:ISD:PORT:SKIP <String>
Tells the ISD tool which ports (in the measured DUT + Test Fixture file) shall be skip-
ped when the tool is run.
Equivalent to using the ports_to_skip batch mode parameter of the ISD tool with a
list of (positive) port numbers.
Parameters:
<String> The port numbers, separated by blanks (e.g. '1 3 4').
Manual operation: See "Ports to Skip (manual)" on page 637
CALCulate:FMODel:ISD:PORT:SKIP:LEFT
CALCulate:FMODel:ISD:PORT:SKIP:NONE
CALCulate:FMODel:ISD:PORT:SKIP:RIGHt
Tells the ISD tool which ports (in the measured DUT + Test Fixture file) shall be skip-
ped when the tool is run.
●
...:LEFT: skip the ports on the left (according to the port order specified using
CALCulate:FMODel:ISD:PORT:ORDer)
●
...:NONE: do not skip any ports
●
...:RIGHt: skip the ports on the right (according to the port order specified using
CALCulate:FMODel:ISD<Ph_pt>:PORT:ORDer)
Equivalent to setting the ports_to_skip batch mode parameter of the ISD tool to -1,
0 or -2, respectively.
Use CALCulate:FMODel:ISD:PORT:SKIP to define an arbitrary set of ports to be
skipped.
Usage:
Event
Manual operation: See "Ports to Skip" on page 637
SCPI command reference
