Command reference
R&S
®
ZNB/ZNBT
1094User Manual 1173.9163.02 ─ 62
Parameters:
<Delay> Delay time
Default unit: s
Manual operation: See "Wait (Sweep Sequencer Table)" on page 560
CONTrol<Ch>:SEGMent<Nr>:GPIO<Port>:VOLTage <Voltage>
For segmented sweeps this command allows to define the GPIO voltage settings to be
applied at the start of each segment.
The GPIO ports can be enabled/disabled using CONTrol<Ch>:GPIO<Port>[:
STATe]. Complementary RFFE commands can be defined using CONTrol<Ch>:
SEGMent<Nr>:RFFE<Bus>:COMMand:DATA.
Suffix:
<Ch>
.
Channel number
<Nr> Segment number
<Port> GPIO port number
Parameters:
<Voltage> Range: -6 to +12 V
Increment: 0.005 V
Default unit: V
Manual operation: See "GPIO columns (sweep sequencer table)" on page 560
CONTrol<Ch>:SEGMent<Nr>:RFFE<Bus>:COMMand:DATA <Command>
For segmented sweeps this command allows to define the RFFE command(s) to be
executed at the start of each segment.
Command execution on an RFFE interface can be enabled/disabled using
CONTrol<Ch>:RFFE<Bus>:SETTings[:STATe]. Complementary GPIO switches
can be defined using CONTrol<Ch>:SEGMent<Nr>:GPIO<Port>:VOLTage.
Suffix:
<Ch>
.
Channel number
<Nr> Segment number
<Bus> RFFE bus interface number
Parameters:
<Command> 3 to 37 hexadecimal digits (0-F), defining the command to be
executed: digit 1 is the slave address, digits 2 and 3 specify the
command number and the remaining digits represent the data
part (up to 17 digit pairs).
Manual operation: See "RFFE columns (sweep sequencer table)" on page 559
SCPI command reference
