R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1118User Manual 1173.9163.02 ─ 62
DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:X:OFFSet <StimulusOffset>
Shifts the trace <WndTr> in horizontal direction, leaving the positions of all markers
unchanged.
Suffix:
<Wnd>
.
Number of an existing diagram area (defined by means of
DISPlay[:WINDow<Wnd>][:STATe] ON).
<WndTr> Existing trace number, assigned by means of DISPlay[:
WINDow<Wnd>]:TRACe<WndTr>:FEED.
Parameters:
<StimulusOffset> Stimulus offset value.
The range and unit depends on the sweep type.
Default unit: NN
Example:
*RST; :DISP:WIND:TRAC:X:OFFS 1MHZ; :DISP:WIND:
TRAC:Y:OFFS 10
Create the default trace and shift it horizontally by 1 MHz, verti-
cally by 10 dB.
Manual operation: See "Stimulus" on page 363
DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:Y:OFFSet <MagnitudeFactor>[,
<PhaseFactor>[, <RealPart>[, <ImaginaryPart>]]]
Modifies all points of the trace <WndTr> by means of an added and/or a multiplied
complex constant. The response values M of the trace are transformed according to:
Suffix:
<Wnd>
.
Number of an existing diagram area (defined by means of
DISPlay[:WINDow<Wnd>][:STATe] ON).
<WndTr> Existing trace number, assigned by means of DISPlay[:
WINDow<Wnd>]:TRACe<WndTr>:FEED.
Parameters:
<MagnitudeFactor> Multiplied magnitude factor
Range: -300 dB to + 300 dB
*RST: 0 dB
Default unit: dB
<PhaseFactor> Multiplied phase factor, optional for setting command but
returned by query
Range: -3.4*1038 deg to +3.4*1038 deg
*RST: 0 deg
Default unit: deg
<RealPart> Real and imaginary part of added complex constant, optional for
setting command but returned by query
Range: -3.4*1038 to +3.4*1038
*RST: 0
SCPI command reference
