R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
871User Manual 1173.9163.02 ─ 62
Manual operation: See "Automatic Mask Generation" on page 707
CALCulate<Chn>:EYE:MASK:CENTer:HORizontal <HorizontalOffset>
Defines the horizontal center of the eye mask in the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<HorizontalOffset> Horizontal offset relative to the middle of the eye diagram
Default unit: s
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Mask Center" on page 706
CALCulate<Chn>:EYE:MASK:CENTer:VERTical
<VerticalOffset>
Defines the vertical center of the eye mask in the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<VerticalOffset> Vertical offset relative to the 0 V level, i.e. the Voltage level of
the center.
Default unit: V
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Mask Center" on page 706
CALCulate<Chn>:EYE:MASK:DATA?
Returns the detailed results of the mask test in the related eye diagram (i.e. the con-
tents of the corresponding result info field).
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram, or if CALCulate<Chn>:EYE:MASK:STATe is OFF.
Use MMEMory:STORe:EYE:MASK:RESults to save these results to an ASCII file.
Suffix:
<Chn>
.
Channel number used to identify the active trace
SCPI command reference
