R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
968User Manual 1173.9163.02 ─ 62
CALCulate<Ch>:PARameter:CATalog?.............................................................................968
CALCulate<Ch>:PARameter:CATalog:SENDed?............................................................... 968
CALCulate<Ch>:PARameter:DEFine:SGRoup.................................................................. 969
CALCulate<Ch>:PARameter:DELete................................................................................970
CALCulate:PARameter:DELete:ALL.................................................................................971
CALCulate<Ch>:PARameter:DELete:CALL.......................................................................971
CALCulate<Ch>:PARameter:DELete:CMEMory................................................................ 971
CALCulate:PARameter:DELete:MEMory...........................................................................971
CALCulate<Ch>:PARameter:DELete:SGRoup.................................................................. 971
CALCulate<Ch>:PARameter:MEASure............................................................................ 972
CALCulate<Ch>:PARameter:MEASure:SENDed............................................................... 972
CALCulate<Ch>:PARameter:SDEFine............................................................................. 973
CALCulate<Ch>:PARameter:SDEFine:SENDed................................................................975
CALCulate<Ch>:PARameter:SELect................................................................................976
CALCulate<Ch>:PARameter:CATalog?
Returns the trace names and measurement parameters of all traces assigned to a par-
ticular channel.
The result is a string containing a comma-separated list of trace names and measure-
ment parameters, e.g. 'CH4TR1,S11,CH4TR2,S12'. The measurement parameters
are returned according to the naming convention of CALCulate<Ch>:PARameter:
SDEFine. The order of traces in the list reflects their creation time: The oldest trace is
the first, the newest trace is the last trace in the list.
Suffix:
<Ch>
.
Channel number. If unspecified the numeric suffix is set to 1.
Example:
CALC4:PAR:SDEF 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the
input reflection coefficient S
11
.
CALC4:PAR:CAT?
Query the traces assigned to channel 4. If Ch4Tr1 is the only
trace assigned to channel 4, the response is 'CH4TR1,S11'.
Usage: Query only
CALCulate<Ch>:PARameter:CATalog:SENDed?
Returns the trace names and measurement parameters of all traces assigned to a par-
ticular channel.
Similar to CALCulate<Ch>:PARameter:CATalog?, but in presence of balanced
ports this command distinguishes between
●
single-ended S-parameters for logical ports (SSS<Li><Lj>)
●
"raw" single-ended S-parameters referring to physical ports (S<Pi><Pj>)
Suffix:
<Ch>
.
Channel number. If unspecified the numeric suffix is set to 1.
Usage: Query only
SCPI command reference
