Chapter 5: Switching Commands 339
The following shows example CLI display output for the command.
(CN1610) >show spanning-tree interface 0/1
Hello Time..................................... Not Configured
Port Mode...................................... Enabled
BPDU Guard Effect.............................. Disabled
Root Guard..................................... FALSE
Loop Guard..................................... FALSE
TCN Guard...................................... FALSE
BPDU Filter Mode............................... Disabled
BPDU Flood Mode................................ Disabled
Auto Edge...................................... TRUE
Port Up Time Since Counters Last Cleared....... 8 day 3 hr 39 min 58
sec
STP BPDUs Transmitted.......................... 0
STP BPDUs Received............................. 0
RSTP BPDUs Transmitted......................... 0
RSTP BPDUs Received............................ 0
MSTP BPDUs Transmitted......................... 0
MSTP BPDUs Received............................ 0
(CN1610) >
The following shows example CLI display output for the command.
(CN1610) >show spanning-tree interface lag 1
Hello Time..................................... Not Configured
STP BPDUs Received Spanning Tree Protocol Bridge Protocol Data Units
received.
RSTP BPDUs
Transmitted
Rapid Spanning Tree Protocol Bridge Protocol Data
Units sent.
RSTP BPDUs
Received
Rapid Spanning Tree Protocol Bridge Protocol Data
Units received.
MSTP BPDUs
Transmitted
Multiple Spanning Tree Protocol Bridge Protocol
Data Units sent.
MSTP BPDUs
Received
Multiple Spanning Tree Protocol Bridge Protocol
Data Units received.
Term Definition
