532 MLD Snooping Commands
show mldsnooping
ssm entries
Use this command to display the source specific multicast forwarding database
built by MLD snooping.
A given {Source, Group, VLAN} combination can have few interfaces in
INCLUDE mode and few interfaces in EXCLUDE mode. In such instances, two
rows for the same {Source, Group, VLAN} combinations are displayed.
show mldsnooping
ssm stats
Use this command to display the statistics of MLD snooping’s SSMFDB. This
command takes no options.
Format
show mldsnooping ssm entries
Mode Privileged EXEC
Term Definition
VLAN The VLAN on which the entry is learned.
Group The IPv6 multicast group address.
Source The IPv6 source address.
Source Filter Mode The source filter mode (Include/Exclude) for the
specified group.
Interfaces 1)If Source Filter Mode is “Include,” specifies the
list of interfaces on which a incoming packet is
forwarded. If it’s source IP address is equal to the
current entry’s Source, the destination IP address is
equal to the current entry’s Group and the VLAN ID
on which it arrived is current entry’s VLAN.
2) If Source Filter Mode is “Exclude,” specifies the
list of interfaces on which a incoming packet is
forwarded. If it’s source IP address is *not* equal to
the current entry’s Source, the destination IP address
is equal to current entry’s Group and VLAN ID on
which it arrived is current entry’s VLAN.
Format
show mldsnooping ssm stats
