640 DiffServ Show Commands
show policy-map This command displays all configuration information for the specified policy.
The
policyname is the name of an existing DiffServ policy.
If the Policy Name is specified the following fields are displayed:
The following information is repeated for each class associated with this policy
(only those policy attributes actually configured are displayed):
Policy Instance Table
Size Current/Max
The current and maximum number of entries (rows)
in the Policy Instance Table.
Policy Instance Table
Max Current/Max
The current and maximum number of entries (rows)
for the Policy Instance Table.
Policy Attribute Table
Max Current/Max
The current and maximum number of entries (rows)
for the Policy Attribute Table.
Service Table Size
Current/Max
The current and maximum number of entries (rows)
in the Service Table.
Term Definition
Format
show policy-map
[policyname]
Mode Privileged EXEC
Term Definition
Policy Name The name of this policy.
Policy Type The policy type (only inbound policy definitions are
supported for this platform.)
Class Members The class that is a member of the policy.
Term Definition
Assign Queue Directs traffic stream to the specified QoS queue.
This allows a traffic classifier to specify which one
of the supported hardware queues are used for
handling packets belonging to the class.
