638 DiffServ Show Commands
DiffServ Show Commands
Use the DiffServ show commands to display configuration and status information
for classes, policies, and services. You can display DiffServ information in
summary or detailed formats. The status information is only shown when the
DiffServ administrative mode is enabled.
show class-map This command displays all configuration information for the specified class. The
class-name
is the name of an existing DiffServ class.
If the class-name is specified the following fields are displayed:
Format
show class-map class-name
Modes ◆ Privileged EXEC
◆ User EXEC
Term Definition
Class Name The name of this class.
Class Type A class type of all means every match criterion
defined for the class is evaluated simultaneously and
must all be true to indicate a class match.
Class Layer3 Protocol The Layer 3 protocol for this class. Possible values
are IPv4 and IPv6.
Match Criteria The Match Criteria fields are only displayed if they
have been configured. Match criteria values are
displayed in the order entered by the user. The fields
are evaluated in accordance with the class type. The
possible Match Criteria fields are: Destination IP
Address, Destination Layer 4 Port, Destination
MAC Address, Ethertype, Source MAC Address,
VLAN, Class of Service, Every, IP DSCP, IP
Precedence, IP TOS, Protocol Keyword, Reference
Class, Source IP Address, and Source Layer 4 Port.
Values The values of the Match Criteria.
