366 VLAN Commands
Port VLAN ID
Current
The current VLAN ID that this port assigns to
untagged frames or priority tagged frames received
on this port. The factory default is 1.
Acceptable Frame
Types
The types of frames that may be received on this
port. The options are 'VLAN only' and 'Admit All'.
When set to 'VLAN only', untagged frames or
priority tagged frames received on this port are
discarded. When set to 'Admit All', untagged frames
or priority tagged frames received on this port are
accepted and assigned the value of the Port VLAN
ID for this port. With either option, VLAN tagged
frames are forwarded in accordance to the 802.1Q
VLAN specification.
Ingress Filtering
Configured
May be enabled or disabled. When enabled, the
frame is discarded if this port is not a member of the
VLAN with which this frame is associated. In a
tagged frame, the VLAN is identified by the VLAN
ID in the tag. In an untagged frame, the VLAN is the
Port VLAN ID specified for the port that received
this frame. When disabled, all frames are forwarded
in accordance with the 802.1Q VLAN bridge
specification. The factory default is disabled.
Ingress Filtering
Current
Shows the current ingress filtering configuration.
GVRP May be enabled or disabled.
Default Priority The 802.1p priority assigned to tagged packets
arriving on the port.
Protected Port Specifies if this is a protected port. If False, it is not
a protected port; If true, it is.
Switchport mode The current switchport mode for the port.
Operating parameters The operating parameters for the port, including the
VLAN, name, egress rule, and type.
Term Definition
