Chapter 5: Switching Commands 419
The following shows example CLI display output for the command
show dot1x
summary 0/1.
Operating
Interface Control Mode Control Mode Port Status
--------- ------------------------ ------------
0/1 auto auto Authorized
If you use the optional parameter 'detail slot/port', the detailed dot1x
configuration for the specified port is displayed.
Operating Control
Mode
The control mode under which this port is operating.
Possible values are authorized | unauthorized.
Reauthentication
Enabled
Indicates whether reauthentication is enabled on this
port.
Port Status Indicates whether the port is authorized or
unauthorized. Possible values are authorized |
unauthorized.
Term Definition
Port The interface whose configuration is displayed.
Protocol Version The protocol version associated with this port. The
only possible value is 1, corresponding to the first
version of the dot1x specification.
PAE Capabilities The port access entity (PAE) functionality of this
port. Possible values are Authenticator or
Supplicant.
Control Mode The configured control mode for this port. Possible
values are force-unauthorized | force-authorized |
auto | mac-based.
Term Definition
