Chapter 5: Switching Commands 421
Supplicant Timeout The timer used by the authenticator state machine on
this port to timeout the supplicant. The value is
expressed in seconds and will be in the range of 1
and 65535.
Server Timeout The timer used by the authenticator on this port to
timeout the authentication server. The value is
expressed in seconds and will be in the range of 1
and 65535.
Maximum Requests The maximum number of times the authenticator
state machine on this port will retransmit an EAPOL
EAP Request/Identity before timing out the
supplicant. The value will be in the range of 1 and
10.
Configured MAB
Mode
The administrative mode of the MAC authentication
bypass feature on the switch.
Operational MAB
Mode
The operational mode of the MAC authentication
bypass feature on the switch. MAB might be
administratively enabled but not operational if the
control mode is not MAC based.
Vlan-ID The VLAN assigned to the port by the radius server.
This is only valid when the port control mode is not
Mac-based.
VLAN Assigned
Reason
The reason the VLAN identified in the VLAN-
assigned field has been assigned to the port. Possible
values are RADIUS, Unauthenticated VLAN, Guest
VLAN, default, and Not Assigned. When the VLAN
Assigned Reason is Not Assigned, it means that the
port has not been assigned to any VLAN by dot1x.
This only valid when the port control mode is not
MAC-based.
Reauthentication
Period
The timer used by the authenticator state machine on
this port to determine when reauthentication of the
supplicant takes place. The value is expressed in
seconds and will be in the range of 1 and 65535.
Term Definition
