650 MAC Access Control List Commands
The
vlan
and
cos
parameters refer to the VLAN identifier and 802.1p user
priority fields, respectively, of the VLAN tag. For packets containing a double
VLAN tag, this is the first (or outer) tag.
The
time-range
parameter allows imposing time limitation on the MAC ACL
rule as defined by the parameter time-range-name. If a time range with the
specified name does not exist and the MAC ACL containing this ACL rule is
applied to an interface or bound to a VLAN, then the ACL rule is applied
immediately. If a time range with specified name exists and the MAC ACL
containing this ACL rule is applied to an interface or bound to a VLAN, then the
ACL rule is applied when the time-range with specified name becomes active.
The ACL rule is removed when the time-range with specified name becomes
inactive. For information about configuring time ranges, see āTime Range
Commands for Time-Based ACLsā on page 687.
The
assign-queu
e parameter allows specification of a particular hardware queue
for handling traffic that matches this rule. The allowed
queue-id value is 0-(n-
1), where n is the number of user configurable queues available for the hardware
platform. The
assign-queue parameter is valid only for a permit rule.
The assign-queue and redirect parameters are only valid for a
permit
rule.
Ethertype Keyword Corresponding Value
appletalk 0x809B
arp 0x0806
ibmsna 0x80D5
ipv4 0x0800
ipv6 0x86DD
ipx 0x8037
mplsmcast 0x8848
mplsucast 0x8847
netbios 0x8191
novell 0x8137, 0x8138
pppoe 0x8863, 0x8864
rarp 0x8035
